// 3D SCANNING — OIL & GAS

Oil & Gas Facility Design

Proport Design provides advanced 3D scanning and facility design for Oil & Gas in Alberta, BC and Saskatchewan. Enhance safety, efficiency, and compliance with precision-driven solutions.

Learn more Watch Video

3D Laser Scanning

Why 3D scanning?

Our expedient data capture and unparalleled accuracy virtually eliminates the risk of errors and by minimizing the amount of personnel and site visits greatly reduces safety infractions. Drawing in the 3D point cloud, we have the ability to see conflicts between your projects current design, and existing facilities, piping and structures before your team reaches site.

How does 3D scanning work?

3D laser scanning emits millions of laser lights and by timing their return, can accurately and precisely calculate their 3D locations, to produce multiple high-speed scans, brought together into one system. It works in conjunction with a total station and gives you a live coordinate based smart model, aka BIM (Building Information Model).

Applications

The technology utilized has a wide array of jobsite applications, and benefits including:

Pre-construction as-builts
BIM (Building Information Model)
Virtual design construction
Quality control during construction
Comparing design intent to As-built
Pre-fabrication of all spools
Estimating inch counts in minutes

Our Services

SERVICE 01

Site Scanning and Virtual Visits

Conduct virtual, photo-realistic visits to project sites using our 5k scan photos, enabling remote assessments and site evaluations for construction and safety requirements. Measure distances, heights, and access points without the need for physical presence.

SERVICE 02

Piping Design and Elimination of Errors

Our skilled scanning crew eliminates costly pipefitting measurement errors by transposing engineered piping into the 3D scanned point cloud model. This ensures conflict resolutions with existing structures and equipment, streamlining fabrication and installation processes.

SERVICE 03

Data Hosting and Sharing

Store and organize project data efficiently with Proport Design. Utilize an intuitive interface to share point cloud data with contractors, providing temporary access throughout the project lifecycle without the need for CAD or 3D skills.

SERVICE 04

Drafting

Structural detailing
P&ID's
Installation/fabrication Isometrics
NWD Models

How we can help

Cost Reduction and Time Savings

Through virtual site visits and accurate measurements, Proport reduces the need for costly on-site visits, streamlines project planning, and improves construction efficiency, ultimately saving time and resources.

Safety and Compliance

Utilize our scanning technology to ensure compliance with safety regulations, assess potential hazards remotely, and plan for safe working conditions during shutdowns and turnarounds.

Enhanced Asset Management

Optimize asset utilization and sustainability by leveraging our precise scanning technology to gather comprehensive site and equipment data, enabling better decision-making and frugal asset reuse.

Frequently Asked Questions About 3D Scanning for Oil & Gas

A tripod mounted laser measures the plant from a series of positions, recording millions of points at each one. Combined, those scans become a dimensionally accurate record of tanks, piping, structures and equipment that your engineers can measure from without going back to site.

3D scanning reduces costs by eliminating measurement errors, minimizing site visits, enabling virtual assessments, and detecting design conflicts before fabrication. Many clients see 80-90% cost reductions through reduced rework, fewer change orders, and optimized project timelines.

Yes. Laser scanning is line of sight and contact free, so there is no hot work and nothing has to be isolated. We plan scan positions with your operations team around access, permits and traffic, and most of a facility can be captured from grade and existing walkways.

A site orientation, an escort where your procedures require one, and any existing drawings so the model matches how your plant is labelled. Knowing which areas are restricted and when they can be accessed lets us plan scan positions in advance and keep time on site short.

The point cloud records the facility as it was actually built rather than as it was drawn, so new spools and supports are modelled against real positions. Clash detection against the existing structure catches interferences before fabrication, which is where most brownfield rework starts.

Our Oil & Gas Projects

See how our 3D scanning and BIM integration transforms facility design across Alberta

Vanguard oil and gas facility complete 3D scan with piping overlay

Vanguard Facility

Complete facility scan with multi-system piping design

Enbridge Facility

BIM integration with contractor coordination zones

Teine battery detailed piping system with labeled specifications

Teine Battery - Piping Design

Pump station 3D scan with equipment mapping

Pump Station - Equipment Mapping

Oil and gas facility with storage tanks and piping infrastructure

Tank Farm - Infrastructure Design

View All Projects

From scan view to site reality

Drag the laser line — the same facility as the scanner sees it, and as your crew sees it.

Oil and gas facility — **FIG. 03** — SCAN VIEW ↔ SITE PHOTO · DRAG THE LASER

**FIG. 03** — SCAN VIEW ↔ SITE PHOTO · DRAG THE LASER
